Learn to solder with easy-to-follow instructions! Ideal for hobbyists and education institutes.
Each kit comes with easy-to-follow pictorial instructions and a 'how to solder and desolder' guide.
Features
- 24 LEDs (extras included)
- Spinning sound
- 1 to 12 LED spin selection
- Push button operation
- 2xAAA battery power (not Incl.)
- Microprocessor technology
- Auto power off in 2 min
Kit Contents
| Component Name | Value | Qty | Designator | Important Info |
| LED 5mm | 5mm | 24 | LED1 ... LED24 | Watch for polarity. Long leg is positive (+) |
| Mini Push Button | 6mm x 6mm | 2 | KEY1, KEY2 | No Polarity |
| Resistors | 330 ohms | 6 | R1 ... R6 | No Polarity |
| Buzzer | 3V | 1 | BUZZER1 | Watch the polarity |
| Integrated Circuit (IC) | STC15W204S | 1 | U1 | Match the ‘notch’ on the silkscreen to the notch on the IC |
| Battery Clip | AAA | 4 | BT1, BT2, BT3, BT4 | Pay attention to the placement direction |
| Capacitor | 100nF | 1 | C1 | No Polarity |
| Desoldering Braid | 6" long (2.5mm width) | 1 | n/a | Use to remove solder when correcting mistakes |
| Stock Code | Product Name |
| DIY-006 | Spinning Wheel DIY Solder Kit |
