Wire Definitions:

Black (-) Red (+) Yellow (signal) • Same as Hitec wire configuration

Brown (-) Red (+) Orange (signal) • Same as JR Wire Configuration



Speed (sec/60°): 0.16 @ 6V, 0.14 @ 7.2V
Torque (Kg.cm): 12.5 @ 6V, 13 @ 7.2V
Size (mm): 40.8 x 20.1 x 38
Weight (g): 58



Downloads

LS-8101F Technical Data Sheet
LS-8101F Sample Code
Stock Code Product Name
LS-8101F Metal Gear Digital Servo
